配件料號(hào)：
| Model No. AR 2000HV(A) | |
| Code | Parts Name |
| 10216 | Nosepiece 'L' 4.8 (3/16) |
| 10226 | Nosepiece 'L' 6.4 (1/4) |
| 29709 | Frame Head 'H' |
| 10447 | Jaw Case Head 'H' |
| 10493 | Ultra Jaws (pair) 'H' |
| 10429 | Jaw Case 'H' |
| 29710 | Jaw Pusher 'H' |
| 29711 | Jaw Pusher Spring 'H' |
| 10448 | Jaw Case Collar 'H' |
| 10449 | Collar Spring 'H' |
| 41203 | Guide Pipe 'E' 4.8 (3/16) |
| 29752 | Guide Pipe 'F' 6.4 (1/4) |
| 10148 | Lock Washer |
| 29712 | Jaw Case Lock Nut 'H' |
| 23634 | Stop Ring |
| 44703 | Frame Unit 'HA' |
| 29337 | Bleed Plug (Hexagon Socket Head Cap Screw) |
| 10355 | Pack Seal 6mm) |
| 29730 | Polyurethane Tube 230mm |
| 29354 | Connector |
| 10128 | O-Ring P-12 |
| 10129 | B-Ring P-12 |
| 41270 | Oil Piston 'Z' |
| 10207 | O-Ring P-24 |
| 10208 | B-Ring P-24 |
| 41216 | Back Piston 'Z' (with 35) |
| 12114 | O-Ring S-7 |
| 41201 | Nozzle Unit (with 25) |
| 41214 | Flange 'Z' |
| 29726 | Return Spring 'H' |
| 29727 | O-Ring S-32 |
| 10192 | Hanger Clip |
| 29690 | Frame Cap 'HV' |
| 29831 | Frame Cap Unit 'HV' (with 19, 29 & 30) |
| 29832 | Air Valve 'H' (with 19 & 33) |
| 10185 | O-Ring S-24 |
| 41222 | Air Controller 'Y' (with 36) |
| 14445 | O-Ring P-30 |
| 29670 | Pan Head Tapping Screw 3x6 |
| 41146 | Mandrel Tank |
| 41149 | Mandrel Tank Unit (with 38) |
| 24311 | O-ring P-34 |
| 29348 | Switch |
| 29350 | Valve Sleeve |
| 42510 | Miniature straight |
| 29729 | Polyurethane tube 125 mm |
| 44551 | Frame cover 'HA-R' |
| 44552 | Frame cover 'HA-L' |
| 29340 | Pan Head Tapping Screw 3x10 |
| 29367 | Flat Head Tapping Screw 5x35 |
| 43586 | Cylinder top (with 44, 45, 46 & 54) |
| 44567 | Muffler 'HA' |
| 29757 | Frame lock nut 'H' |
| 29736 | Rubber cushion 'H' |
| 29758 | Air piston unit 'H' |
| 10212 | O-ring P-70 |
| 29741 | Cylinder cup 'H' |
| 29361 | Grommet |
| 10276 | O-ring S-5 |
| 29740 | Cylinder cover 'H' |
| 10274 | O-ring P-10 |
| 10149 | O-ring P-7 |
| 29375 | Change plug |
| 29610 | Pan Head Tapping Screw 4x20 |
| 29739 | Cylinder bottom 'H' |
| 29612 | Spool |
| 29613 | O-ring P-5(4D) |
| 29614 | O-ring P-8(4D) |
| 10219 | O-ring P-9 |
| 10012 | "LOBSTER" brand hydraulic oil |
| 29642 | Spanner 'B' |
| 10217 | Spanner 'A' |
| 25777 | Hex key wrench 5 mm |
| 29624 | Priming pump (syringe unit) |
| 20916 | Cross recessed head screw 6x10 |
| 42501 | Rotary joint |
| 10285 | Retaining ring E-7 |
| 10149 | O-ring P-7 |
| 42479 | Nipple |
| 41299 | Plate |
| 10151 | O-ring S-10 |
| 42502 | Rotary joint unit |
